Pu Foam-FA
Multi purpose type
Leader of China Manufacturer in Pu Foam and Building Adhesive Industry.
SHUODE manufacturer low VOC fire rated polyurethane pu foam support OEM
SHUODE manufacturer low VOC fire rated polyurethane pu foam support OEM compared with similar products on the market, it has incomparable outstanding advantages in terms of performance, quality, appearance, etc., and enjoys a good reputation in the market.Shuode summarizes the defects of past products, and continuously improves them. The specifications of SHUODE manufacturer low VOC fire rated polyurethane pu foam support OEM can be customized according to your needs.
5.0
Price:
2000-5999 Pieces$2,>=30000 Pieces$1
Customization:
Min. Order: 12000PCS
shipping:
Sea freight
samples:
2pcs free
Lead_Time:
15-30days
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
| CAS No.: | 7085-85-0 | Other Names: | insulation foam spray |
| MF: | Mixture | EINECS No.: | 230-391-5 |
| Place of Origin: | Shanghai, China | Classification: | Hot Melt Adhesives |
| Main Raw Material: | POLYURETHANE | Usage: | Construction, Fiber & Garment, Footwear & Leather, Packing, Transportation, Woodworking, polyurethane foam |
| Brand Name: | SHUODE | Model Number: | FR |
| Type: | fire retardant pu foam | Item name: | polyurethane spray foam |
| Cuttable time (30mm diameter (minute): | Approx.60 | Fire Retardant Factor: | B2 |
| Optimal Application Temp.(℃): | +5~+35 | Min. Application Temp.(℃): | +18~+25 |
| Tensile Strength(Aluminum Plate)(KPA): | 120 | Temp. Resistance(Long Term)(℃): | -30~+80 |
| Temp. Resistance(Short Term)(℃): | -40~+110 | Expansion Multiple(time): | Max.80 |
| Density(KG/M3): | 19±6 |
Product Introduction
Flame retardant polyurethane foam is a FR series specially developed for hot, fire-prone areas. It keeps our doors and Windows from catching fire and starting a bigger fire. However, the Foam amount of this Pu Foam Spray is slightly lower due to the addition of flame-retardant material, so the actual usage is less than that of multi-functional polyurethane Foam adhesive with the same weight.However, its adhesion can fully meet the use of our household doors and Windows and other scenes, such as the entrance and exit of wire in the wall, which can effectively prevent the occurrence of fire.
Product Parameters
| Iteam | Stardand | Result |
|---|---|---|
| Base | Polyurethane | Pass |
| Consistency | Stable Foam | Pass |
| Curing System | Moisture-cure | Pass |
| Tack-Free Time (min) | 8~15 | Pass |
| Drying Time | Dust-free after 20-25 min | Pass |
| Cutting Time (hour) | 1 (+25℃) 8~12 (-10℃) | Pass |
| Yield (L) | 50 | Pass |
| Shrink | None | Pass |
| Post Expansion | None | Pass |
| Cellular Structure | 70~80% closed cells | Pass |
| Specific Gravity (kg/m³) | 20-25 | Pass |
| Temperature Resistance | -40℃~+80℃ | Pass |
| Application Temperature Range | -5℃~+35℃ | Pass |
| Color | Champagne | Pass |
| Fire Class (DIN 4102 ) | B2 | Pass |
| Insulation Factor (Mw/m.k) | <20 | Pass |
| Compressive Strength (kPa) | >180 | Pass |
| Tensile Strength (kPa) | >30 (10%) | Pass |
| Adhesive Strengh(kPa) | >120 | Pass |
| Water Absorption (ML) | 0.3~8(no epidermis) <0.1(with epidermis) | Pass |
| CONCLISON:Shuode Pu Foam FR Grade Confirmed ISO9001. | ||
Product Details
Polyurethane Foam Gun Stype
It needs to be used with glue gun. Pu Foam with Gun Stype will be used more often.
Polyurethane Foam Straw Type
We will have a free plastic tube, which is more foaming, slightly less use.
Product Features
Flame retardant
Shuode FR series polyurethane foam is B2 fireproof grade.
Regular polyurethane styrofoam will continue to burn, but flame retardants will not ignite at all.
Difference from ordinary
Adhesive Testing
Adhesive Compressive>250KPA
Compressive Strength Testing
It can bear 70KG
Denisity&Close Cell
Small Bubble,No Oil Leakage,No Powder
Factory Pictures
Shuode's factory covers an area of 50,000 square meters, with a workshop area of 40,000 square meters. Shuode is one of the earliest manufacturers of polyurethane foam in China. We have more than 20 years of experience in the field of polyurethane foams, and a variety of foaming agents developed have been granted national patents and passed ISO 9001 and ISO 14001.
Shuode has ten automatic polyurethane foam production lines, which are fully automated.
We have an independent laboratory to research more advanced high expansion polyurethane foam.
We have two large warehouses to store customers'spare parts and our own branded products.
We have more than 10 years of cooperative freight forwarders, the factory is only 4 hours away from Qingdao port in China, very convenient.
FAQ
Q1. What is your terms of payment for Foam Sealant?
A: TT 30% as deposit, and 70% before delivery. We’ll show you the photos of the products and packages before you pay the balance.
Q2. Do you test all your goods before delivery the Foam Sealant?
A: Yes, we have 100% test before delivery the pu expanding foam
Q3. How about your delivery time?
A: Generally, it will take 7 to 30 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q4. What is your terms of delivery?
A: EXW, FOB, CIF for pu expanding foam
Q5. How do you make our business long-term and good relationship
A1: We keep good quality and competitive price to ensure our customers benefit ;A2: We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
Our services
Oem or odm are acceptable.
We accept small order/trial order for customer to check whether the products is suitable for the market.
Will be available online almot in 24 hours service for your esteemed company.
We are glad to hear from you soon and to start a business relationship with your esteem company.
If you have another questions,please feel free to contact us.
